Page 16 KACO blueplanet 1000/875/750 TL3 M1 IS OD DEX0
Unit Description
DC input side
1
2
3
4
6
5
Figure 8: Components inside the inverter (DC input side)
Key
1 Overvoltage protection (SP1-DC side) 4 DC connection
2 DC current transformer 5 EMC1 (EMC filter on DC)
3 Fuse protection for voltage supply 6 ECFAN (Enclosure circulation FAN)
