Page 18 KACO blueplanet 1000/875/750 TL3 M1 IS OD DEX0
Transportation and Delivery
4.3 Centre of Gravity of the Inverter
The centre of gravity of the inverter is not in the middle of the BP1000/875/750 TL3 OD DE. Take this into con-
sideration when transporting the BP1000/875/750 TL3 OD DE.
The centre of gravity of the inverter is marked with the centre of gravity symbol on the packaging and the enclo-
sure.
Left Front
1150mm
247mm
3400mm
2500mm
Figure 9: Centre of gravity by Front side
1112mm
1800mm 650mm
1112mm
Back Right
Figure 10: Centre of gravity by Rear side
