KACO blueplanet 1000/875/750 TL3 M1 IS OD DEX0 Page 25
Storage/Installation/Start-up
5.4 Connecting the conduit
In this section, see how to insert the cables in the inverter and where to punch the holes for the conduit fittings.
NOTE
When installing, please be cautious that water is not able to enter into the inside of
the cabinet.
Moisture can affect the performance of the inverter through improper conduit or
hubs.
There are two ways of connecting cables shown in the following figures.
The field wiring area is designed for DC cable, AC cable and data cables.
The conduit entry points can be used for any cables. Example: DC conduit is on bottom of left side and AC
conduit is on bottom of right side.
Using the DC conduit panel and AC conduit panel for cables.
" Remove the bolts which secure the plate to the inverter.
" Remove the plate.
" Mark all the holes for the conduit. You need conduit for AC, DC and data cables.
" Punch holes for the conduit.
" Attach the plate to the inverter.
" Attach the bolts and tighten.
" Ensure that proper conduit duct sealant is used to prevent rodent and insect infestation.
" The bottom plate must be secured in place during operation. If conduit is used, the proper conduit
fittings must be used.
