Page 50 KACO blueplanet 1000/875/750 TL3 M1 IS OD DEX0
Storage/Installation/Start-up
Configure the network for the MMI
" Select static and dynamic IP addresses via DHCP service requests.
" Change the web port used for monitoring the inverter via the web.
" Open the web monitoring service using the HMI`s IP address and web port (e.g. http://192.168.10.3:80).
WiFi
SSID HMI Set
Reset
Modbus
Config
Port
ON
502
Set
Set
Figure 47: “WiFI” screen Figure 48: “Modbus” screen
Configure the WiFi for the HMI
" Change the SSID used for monitoring the inverter via the Wireless.
Configure the Modbus for the HMI
" Open the Modbus communication service using the HMI`s IP address and port (e.g. 192.168.10.3:502).
5.11.15 Software upgrade
If an update is available (for example, when new functions are added), use the SD card to update the inverter
software.
SAFE
NOTE
Do not remove the SD card until the SAFE icon is displayed so that it will be detected by the
HMI when you reinsert it.
