TA Triumph-Adler P-C3560i MFP - Manual (Page 73)

2-26
Installing and Setting up the Machine > Default Settings of the Machine
Wireless Network Settings
When the optional Wireless Network Interface Kit is installed on the machine and the connection settings are configured,
it is possible to print in a wireless network (wireless LAN) environment. The following is an introduction to the settings for
connecting using the Quick Setup.
The following four settings can be configured in Quick Setup.
Setup (page 8-32)
Available Network
Displays access points to which the machine can connect.
Push Button
If the access point supports the push button method, wireless settings can be configured using the push button. This
setting executes push button, and the connection is started by pressing the push button on the access point.
PIN (Device)
Starts connection using the machine's PIN code. Enter the PIN code into the access point. The PIN code of the machine
is automatically generated.
PIN (Terminal)
Starts connection using the PIN code of the access point. Enter the PIN code of the access point.
IMPORTANT
After changing the setting, restart the network from System Menu, or turn the
machine OFF and then ON.
Restart Network (page 8-31)
NOTE
The push button method supports only the WPS.
