MVI94-DNP ♦ Flex I/O Reference
DNP 3.0 Server over Ethernet Communication Module User Manual
ProSoft Technology, Inc. Page 99 of 131
December 17, 2010
Variable
Name Data
Range Description IF Error Config.
Value
Analog Inputs: 0 TO 120 Number of analog input points to configure
in the DNP slave device. Each point will
occupy a one word area in the module
memory.
0
Float Inputs: 0 TO 60 Number of float input points to configure in
the DNP slave device. Each point will
occupy a double-word area in the module
memory.
0
Double Inputs: 0 TO 30 Number of double input points to configure
in the DNP slave device. Each point will
occupy a four-word area in the module
memory.
0
Counters: 0 TO 30 Number of counter points to configure in the
DNP slave device. Each point will occupy a
two word area in the module memory. This
number corresponds to the number of
frozen counters. The application maps the
counters to the frozen counters directly.
0
Binary
Outputs:
0 TO 960 Number of digital output points to configure
in the DNP slave device. Each point will be
stored as a single bit in the module
memory.
0
Analog
Outputs:
0 TO 60 Number of analog output points to configure
in the DNP slave device. Each point will
occupy a one word area in the module
memory.
0
Float Outputs: 0 TO 60 Number of float output points to configure in
the DNP slave device. Each point will
occupy a double-word area in the module
memory.
0
Double
Outputs: 0 TO 30 Number of double output points to configure
in the DNP slave device. Each point will
occupy a four-word area in the module
memory.
0
Variable
Name Description
[DNP Slave
Binary Inputs]
This section is used to override the default values of the class
assignment for the binary input points.
# Point# Class
START This string signals the start of the point definition list.
0 1
1 2
2 3
END This string signals the end of the point definition list.
Variable
Name
Description
