Chapter 5. The User Interface
83
2. Click
Add
; then select the media source.
Depending on your selection, additional dialog boxes appear to enable you
to select the drive, ISO file, folder, or removable disk you desire.
See
, page 283 for a list of supported virtual media
types, and details about mounting them.
3. If your device only supports full speed USB, put a check in the
Disable
High Speed USB Operation Mode
checkbox.
4. To add additional media sources, click
Add
, and select the source as many
times as you require. Up to three virtual media choices can be mounted.
The top three in the list are the ones that are selected. Virtual Media and
Smart Card readers can be mounted at the same time. To rearrange the
selection order, highlight the device you want to move, then click the Up
or Down Arrow button to promote or demote it in the list.
5.
Read
refers to the redirected device being able to send data to the remote
server;
Write
refers to the redirected device being able to have data from
the remote server written to it. For the redirected device to be writable as
well as readable, click to put a check in the
Enable Write
checkbox:
Note:
If a redirected device cannot be written to, it appears in gray.
