Chapter 5. The User Interface
79
Gamma Adjustment
If it is necessary to correct the gamma level for the remote video display, use
the
Gamma
function of the Video Settings dialog box.
Under
Advanced
configuration, there are ten preset and four user-defined
levels to choose from. Drop down the list box and choose the most suitable
one.
For greater control, clicking the
Advanced
button brings up the following
dialog box:
Click and drag the diagonal line at as many points as you wish to achieve
the display output you desire.
Click
Save As
to save up to four user-defined configurations derived from
this method. Saved configurations can be recalled from the list box at a
future time.
Click
Reset
to abandon any changes and return the gamma line to its
original diagonal position.
Click
OK
to save your changes and close the dialog box.
Click
Cancel
to abandon your changes and close the dialog box.
Note:
For best results, change the gamma while viewing a remote server.
