ATEN KN Series 32-Port KVM over IP Switch with Dual Power/LAN (1-Local + 4-Remote Access) - Manual (Page 87)

Chapter 5. The User Interface
69
3. Click Record .
The dialog box disappears, and a small panel appears at the top left of the
screen:
4. Press the keys for the macro.
Š
To pause macro recording, click Pause . To resume, click Pause again.
Š
Clicking Show brings up a dialog box that lists each keystroke that you
make, together with the amount of time each one takes:
Š
Clicking Cancel cancels all keystrokes.
Š
When you have finished, click Stop . (This is the equivalent of
clicking Done in Step 5.)
Note: 1. Case is not considered – typing A or a has the same effect.
5. When recording the macro the focus must be on the remote
screen. It cannot be in the macro dialog box.
2. Only the default keyboard characters may be used. Alternate
characters cannot be used. For example, if the keyboard is
Traditional Chinese and default character is
A the alternate
Chinese character obtained via keyboard switching is not
recorded.
