Appendix
263
PPP Modem Operation
Basic Setup
The KVM over IP switch can be accessed through its RS-232 port using a PPP
dial-in connection, as follows:
1. Set up your hardware configuration to match the diagram, below:
:
2. From your client computer, use your modem dial-in program to dial into
the KVM over IP switch’s modem.
Note: 1. If you don’t know the KVM over IP switch modem’s serial
parameters, get them from the KVM over IP administrator.
2. An example of setting up a modem dial-in program under
Windows XP is provided on the next page.
3. Once the connection is established, open your browser, and specify
192.168.192.1 in the URL box.
Note: 1. The default username and password are blank.
2. For the modem session, the KVM over IP switch has an IP
address of 192.168.192.1; the user side has an IP address of
192.168.192.101.
From here, operation is the same as if you had logged in from a browser or with
the AP programs.
Remote
Operator
Modem
Modem
Phone Line
Serial Modem Cable
Cat 5e Cable SA0142
(DB9-M, DTE - DCE)
