KVM over IP Switch User Manual
258
IPv6
At present, the KVM over IP switch supports three IPv6 address protocols:
Link Local IPv6 Address , IPv6 Stateless Autoconfiguration , and Stateful
Autoconfiguration (DHCPv6) .
Link Local IPv6 Address
At power on, the KVM over IP switch is automatically configured with a Link
Local IPv6 Address (for example, fe80::210:74ff:fe61:1ef). To find out what
the Link Local IPv6 Address is, log in with the KVM over IP switch’s IPv4
address and open the
Device Management
→
Device Information page. The
address is displayed in the General list box (see page 156).
Once you have determined what the IPv6 address is, you can use it when
logging in from a browser or the Win and Java Client AP programs.
For example:
If you are logging in from a browser, you would key in
http://[fe80::2001:74ff:fe6e:59%5]
for the URL bar.
If you are logging in with the AP program, you would key:
fe80::2001:74ff:fe6e:59%5
for the IP field of the Server panel (see Windows Client AP Login , page 47).
Note: 1. To log in with the Link Local IPv6 Address, the client computer must
be on the same local network segment as the KVM over IP switch
2. The %5 is the %interface used by the client computer. To see your
client computer’s IPv6 address: from the command line issue the
following command:
ipconfig /all . The % value appears at the
end of the IPv6 address.
