No.
Name
Function
It detects overlapped documents by monitoring the
difference in the amount of ultrasonic waves transmitted
through the documents.
3
Brake roller (× 2)
A roller that prevents more than one sheet of documents to
be fed into the ADF at once.
4
Document sensor (× 8)
A sensor which detects whether there is a document.
5
Glass (× 2)
The surface which scans documents.
6
Feed roller (× 2)
A roller that feeds the document through the ADF.
7
Eject roller (× 2)
Rollers that feed documents from the ADF onto the stacker.
8
Pick roller (× 2)
A set of rollers which separates one sheet off the
documents loaded in the ADF paper chute (feeder), and
feeds the document into the ADF.
9
Plastic idler roller (× 4)
A roller that feeds the document through the ADF.
