Fujitsu Ricoh Fujitsu fi-7300NX Color Duplex Document Scanner - Manual (Page 310)

Appendix
Basic Specification
Item Specification
Scanner type ADF (Automatic Document Feeder)
Manual feeding (Single/Continuous) is available with
the ADF.
Image sensor Color CCD × 2 (front, back)
Light source White LED × 2 (front, back)
Scanning area (width ×
length) Minimum size 50.8 × 54 mm/2 × 2.1 in.
54 × 50.8 mm/2.1 × 2 in.
Maximum size A4 (portrait) (210 × 297 mm/8.3 × 11.7 in.) (*1)
Legal (portrait) (8.5 × 14 in.) (*1)
Paper weight (thickness)
27 to 413 g/m 2 (7.2 to 110 lb)
For A8 size or smaller, 128 to 209 g/m 2 (34 to 56 lb)
1.4 mm or less for plastic cards (*2)
Scanning speed (A4,
Portrait, 300 dpi) (*3) For USB connection Simplex: 60 ppm, Duplex: 120 ipm
For wired LAN connection Simplex: 60 ppm, Duplex: 120 ipm
For Wi-Fi connection Simplex: 60 ppm, Duplex: 120 ipm
Loading capacity (*4) 80 sheets
Paper weight: 80 g/m
2 (20 lb)
Total thickness: 8 mm (0.3 in.) or less
Optical resolution 600 dpi
Output resolution Binary (black & white) 50 to 600 dpi (configurable in 1 dpi increments)
1,200 dpi (created by scanner driver)
Grayscale
Color
Multi-valued level Color: 24-bit
Grayscale: 8-bit
Binary (black & white): 1-bit
Interface USB USB 3.1 Gen 1/USB 3.0/USB 2.0/USB 1.1 (*5)
Type B
Wired LAN IEEE802.3 Ethernet
10BASE-T/100BASE-TX/1000BASE-T
RJ-45
310
