Section 3
Auto-Zone Basic
3-14 Programming
Zone Manager Setpoints
The Zone Manager Setpoints are kept separate from the Zone Manager Configuration
setpoints since these are the most commonly changed values. Enter the number shown
below for the desired selection. When you are finished, press the "A" key to return to the
Main Menu.
Zone Manager Setpoint Menu
Week Schedules
Schedule Start Time
Schedule Stop Time
Note: The second line displays which day of the week is currently being programmed.
This automatically increments as you finish the Stop Time and continue to the
next Start Time screen.
1) Control Setpoints
2) Schedules
3) Holidays
4) Time & Date
WEEK SCHEDULES
Sunday Stop Time
Enter Hrs/Mins: 0
(MILITARY FORMAT)
The screens will step through the Start Time and then the Stop
Time for each day of the week. You can quit at any point in
the process by pressing the "A" key.
All times are in 24-hour format, so 5:00 PM would be entered
as 1700.
WEEK SCHEDULES
Sunday Start Time
Enter Hrs/Mins: 0
(MILITARY FORMAT)
If both the Start and Stop Times are ZERO, the schedule is in
a continuous OFF mode.
If both the Start and Stop Times are 2359, the schedule is in a
continuous ON mode.
