111
SIP Proxy mode
Figure 193. Topology of instruction example - Proxy mode
To connect to a SIP server, you can carry out the following steps:
Step 1: Make sure the VIP-191_A is connected to an AP.
Step 2: From the Main Screen, press the Left (“Menu”) Key and select “3. Profile Setting”. Select
“Standard”, press OK and select “Edit Profile” from the submenu, just as shown below:
Figure 194. Profile setting of VIP-191
Step 3: Fill in the corresponding information. Usually the fields that need to be filled are: “My Phone
Number”, “SIP Server” (i.e. domain name or IP address of SIP server), “Account Name”, and “Account
Password”, and you can leave the other fields with the default values. An example:
My Phone Number: [email protected]
SIP Server: 172.0.0.1
Account Name: 882
Account Password: 123
The SIP standard requires you to include the “@” sign and
the SIP server domain in the My Phone Number field.
L
Hint
