BPS / MX / RS Series SCPI Programming Manual AMETEK Programmable Power
Manual P/N 7003-961 Rev. AA 113
4.23 Status Subsystem Commands
This subsystem programs the AC/DC power source status registers. There are four groups
of status registers;
• Operation Status Group
• Questionable Status Group
• Questionable Instrument Isummary Group
• Standard Event Group
The Standard Event group is programmed with Common commands. The Operation,
Questionable, and Instrument ISummary status groups each consist of the following three
registers:
Condition Enable Event
Refer to chapter 7 for more information about the status registers.
Subsystem Syntax
STATus
:OPERation
:EVENt Returns the value of the event register
:CONDition Returns the value of the condition register
:ENABle <n> Enables specific bits in the Event register
:QUEStionable
:EVENt Returns the value of the event register
:CONDition Returns the value of the condition register
:ENABle <n> Enables specific bits in the Event register
:INSTruments
:ISUMmary
:EVENt Returns the selected phase’s event register value
:CONDition Returns the selected phase’s condition register
:ENABle Enable specific bits in selected phase’s Event
register values
Bit Configuration of Status Operation Registers
Bit Position 15-5 4 3 1-2 0
Bit Name not used MEAS TRANS not used CAL
Bit Weight 16 8 1
CAL Calibration is completed
TRANS Transient is completed
MEAS Measurement is completed
