BPS / MX / RS Series SCPI Programming Manual AMETEK Programmable Power
Manual P/N 7003-961 Rev. AA 203
REGenerate:DELay:FREQuency[:SHUTdown]
This command will set the delay in seconds before applying the programmed frequency
deviation in an attempt to shut down the inverter under test. Available setting range is 0.25
to 10.0 seconds. If the frequency deviation is set to 0.0 Hz, no frequency shift will be
asserted. If set to a value other than zero hertz, the frequency shift will be applied when the
fed back current exceeds the programmed current limit for more than the delay set by the
REG:DEL:FREQ command.
Command Syntax REGenerate:DELay:FREQuency[:SHUTdown] <Nrf>
Parameters 0.25 to 10, time in seconds.
Examples REG:DEL:FREQ 3
Query Syntax REGenerate:DELay:FREQuency[:SHUTdown]?
Returned Parameters <NR2>
REGenerate:DELay:OUTPut[:SHUTdown]
This command will set the delay in seconds before shutting down the power source output in
an attempt to shut down the inverter under test. Available setting range is 0.25 to 10.0
seconds. If the frequency deviation is set to 0.0 Hz, no frequency shift will be asserted. If set
to a value other than zero hertz, the frequency shift will be applied first when the fed back
current exceeds the programmed current limit for more than the delay set by the
REG:DEL:FREQ command. If the current fed back by the EUT still exceeds the programmed
current limit, the output voltage will be set to the lower voltage limit and the output relay will
open after this delay expires.
Command Syntax REGenerate:DELay:OUTPut[:SHUTdown] <Nrf>
Parameters 0.25 to 10, time in seconds.
Examples REG:DEL:OUTP 3
Query Syntax REGenerate:DELay:OUTPut[:SHUTdown]?
Returned Parameters <NR2>
REGenerate:DEViate:FREQuency
This command will set or query the frequency shift used to shut down the inverter under test.
Available setting range is 0.0 to 5.0 Hz. If the frequency deviation is set to 0.0 Hz, no
frequency shift will be asserted. If set to a value other than zero hertz, the frequency shift will
be applied when the fed back current exceeds the programmed current limit for more than
the delay set by the REG:DEL:FREQ command.
Command Syntax REGenerate:DEViate:FREQuency <Nrf>
Parameters 0 to 5
Examples REG:DEV:FREQ 3
Query Syntax REGenerate:DEViate:FREQuency?
Returned Parameters <NR2>
