AMETEK Programmable Power BPS / MX / RS Series SCPI Programming Manual
172 Manual P/N 7003-961 Rev AA
8. Option Commands
8.1 Introduction
The MX/RS Series offers a number of options that are implemented in the power source
controller. If one or more of these options are installed, they may be used from both the
front panel and the interface. For front panel operation of any of these firmware options,
consult the User Manual supplied with the unit. For use in an automated test system, this
chapter contains the command sub system syntax for the available test options.
Specifically, the following firmware options are available at the time of this manual’s printing:
• IEC 61000-4-11, Option -411
• IEC 61000-4-13, Option -413
• MIL-STD 704E, Option -704
• RTCA/DO-160D, Option –160
• Airbus ABD0100.1.8 Option -ABD (Requires MXGui Windows Software. No SCPI
commands available.)
• Airbus AMD24 Option -AMD
(Requires MXGui Windows Software. No SCPI
commands available.)
• Boeing B787-0147 Option –B787 (Requires MXGui Windows Software. No SCPI
commands available.)
• OMNI
Option
• WattHour Meter, Option -WHM
The AC/DC power source will report all installed options, including any firmware options,
when queried using the SYST:CONF:BYTE? or *OPT? command. Additional firmware
options may be added over time. Consult the factory for additional information on firmware
options not listed here but present on your unit.
