BPS / MX / RS Series SCPI Programming Manual AMETEK Programmable Power
Manual P/N 7003-961 Rev. AA 117
4.24 System Commands
The system commands control the system-level functions of the AC/DC Source.
Subsystem Syntax
SYSTem
:ERRor? Returns the error number and error string
:VERSion? Returns the SCPI version number
:HISTory
[:RECords]? Return record data for the source when fault occurs
:LOCal Go to local mode (RS-232 only)
:REMote Go to remote mode (RS-232 only)
:CONFigure Set system configuration, password required
[:BYTE]
NOUT Set the number of output phases (one or three) if
the mode option is available
:ETIMe? Returns the elapse time
:TEMPerature Returns the internal ambient temperature in °C
:COMMunicate
:GPIB
:ADDRess Set GPIB address
:LAN
:ADDRess Set LAN IP address
:APPLy Apply the change in setting
:CLASs Set LAN Host bits
:DEFault Set LAN to a default known setting
:DESCription Set user description
:DNSaddress Set LAN DNS address
:GWADdress Set LAN Gateway
:HOST Set the Host name.
:PASSword Set LAN password
:PORT Set LAN socket port address
:SERial
:BAUD
Set the baud rate
:PARity Set the parity type
:BITS Set number of bits
:SBITs Set number of stop bits
SYSTem:ERRor?
This query returns the next error number followed by its corresponding error message string
from the remote programming error queue. The queue is a FIFO (first-in, first-out) buffer that
stores errors as they occur. As it is read, each error is removed from the queue. When all
errors have been read, the query returns 0,No Error. If more errors are accumulated than
the queue can hold, the last error in the queue is -350,Too Many Errors.
Query Syntax SYSTem:ERRor?
Parameters None
Returned Parameters
<NR1>,<SRD>
Example SYST:ERR?
SYSTem:VERSion?
