BPS / MX / RS Series SCPI Programming Manual AMETEK Programmable Power
Manual P/N 7003-961 Rev. AA 177
8.3 IEC 1000-4-13 (-413)
8.3.1 IEC 1000-4-13 Subsystem
The following are the remote commands set for IEC1000-4-13. The ABORt command will
terminate the test in progress at any time. Test completion can be checked using the
*OPC? query if the *OPC 1 command is issued immediately after an IEC1000-4-13 RUN
command. Upon completion of the test run, *OPC? will return a 1. This may be relevant for
ATE applications in view of long test times.
Firmware revision note: Support for the Meister curve test was added with firmware
revision 0.31. There are some new commands associated with this test that will only be
supported if the unit you are using has firmware revision 0.31 or higher.
:IEC413
:STATe Enable or disable the IEC test.
:RUN Run the IEC test
:PAUSe Pause test
:CLASs <2|3|USER>
:INDVidual
:HARMonics
[:NUMber] Set the IEC harmonic number.
:IHARmonics
[:FREQuency] Set the IEC interharmonics frequency.
:SWEep
[:RANGe] Set the Sweep range
:STEP
[:SIZE]
Set sweep step size.
:GROUp Select the IEC group.
:FCURve
:LEVel Set flat curve level.
:DWELl Set flat curve dwell time.
:PAUSe Set flat curve pause time
:MCURve
:LEVel
Set mcurve levels.
:DWELl Set mcurve dwell time
:PAUSe Set mcurve pause time
:OSWing
:LEVel Set over swing level.
:PHASe Set over swing harmonic phase angle.
:DWELl Set over swing dwell time
:PAUSe Set over swing pause time.
:SWEep
:LEVel Set sweep interharmonics level
:DWELl Set sweep dwell time.
:CURRent
[:DATA]? Get interharmonics current.
:RESonant? Get interharmonics current at resonant
:FREQuency
[:DATA]? Get interharmonics frequency
:RESonant? Get interharmonics frequency at resonant
:HARMonics
:LEVel Set harmonics level.
:PHASe Set harmonics phase.
:DWELl Set harmonics dwell.
