Mechanical Computer and Reset Section
Mechanical Computer, Reset, and Pulser with Electrical Keytrol
Page 106 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Item#
Part Description
Current Part
Previous Part
1 Electrical
Keytrol
-
-
2
Elbow, Conduit, 1/2” X 90º M/F
025045
-
3
Reset Assembly 110 V 60 Hz EK Pump
048810
-
Reset Assembly 230 V 60 Hz EK Pump
048811
-
Reset Assembly 230 V 50 Hz EK Pump
048812
-
Reset Assembly 110 V 60 Hz EK Dispenser
048813
-
Reset Assembly 230 V 60 Hz EK Dispenser
048814
-
Reset Assembly 230 V 50 Hz EK Dispenser
048815
-
4
Pipe TBE, 1/2 X 1-1/8 Zinc Plated
N16771-78
-
5
Conduit, 1/2 X 8-3/4
021301
-
6
Conduit, 9100ATW EK
069726
-
7
1/2 UNY Explosion-proof Cond Union
N16289-20
-
8
Conduit, 1/2 X 6-3/4
021347
-
9
Screw, 1/4-20 X 1/2 HHC
K05287
-
10
Lock Nut, 1/2 NPT Machined
K89681
-
11
Washer Flat 0.875 X 1.62 X 0.056
N16599-59
-
12
Conduit, 1/2 X 3 NPS Threads
021737
-
13
Elbow, Conduit 1/2 X 90 F/F MCH
025030
-
14 Conduit
Tee
064830
-
15
Conduit, 1/2 X 2
021337
-
16
Screw, 1/4-28 X 5/8 HHC
Q10624-37
-
17
Lock Washer, Ext 1/4 1114
068891
-
18 Gear,
Quantity
027041
-
19
Hub, Quan. Shaft Extension
031035
-
20
Pin, Spirol 5/64 X 7/16 STD PL
Q10038-35
-
21
Plate and Idler Gear Assembly
027044
-
22 Plate,
Mounting
046970
-
23
Ring Ret 5133-25-ZF
K76238-41
-
24
Screw, 1/4-20 X 5/8 Wash HD Type-T
K85736-39
-
26
Decal, 10:1 Pulser
023596
-
27 Non-Computer,
Gallon
021079
-
Non-Computer, Liter
021071
-
28
Pulser Assembly 10:1
046973
-
Pulser Assembly 1:1
046969
-
Pulser Assembly 100:1
046972
-
29
Screw, 1/4-20 X 5/8 HHC
K14830
-
31 Spacer
056877
-
32
Elbow, Conduit 1/2 X 45 M/F
025015
-
33
Pipe TBE, 1/2 X 1-1/2 Zinc Plated
R11979-39
-
