Ultra-Hi Frame Section
Dispenser Frame
Page 118 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Dispenser Frame
Item #
Part Description
Current Part
Previous Part
Quantity
1
Base Rail Frame Support
M04460B001
-
2
2
Column Cross Support Bracket
M04251B001
-
2
3
Screw, TF, Hex Washer HD M8 X 18
M00417B009
-
4
Dispenser Lower Frame
Item #
Part Description
Current Part
Previous Part
Quantity
1
Base Rail Frame Support
M04460B001
-
2
2
Bracket, Lower Panel Lock
M04774A001
-
2
3
Column Cross Support Bracket
M04251B001
-
2
4
Column, Lower Frame
M06628A001
-
2
5
Nut, Metric, Hex Serrd Flg (M8)
M00414B003
-
4
6
Plate, Inlet Fitting Support
M05538B001
-
1
7
Rail Meter Support
M05537B001
-
2
8
Screw, TF, Hex Washer HD M8 X 18
M00417B009
-
40
Dispenser Upper Frame
