Gasboy Atlas Commercial Series - Manual (Page 137)

Item # Part Description Current Part Previous Part Quantity
1 Motor, 1 - 1/2 HP 230 V 1PH 60Hz F37340 - 1
2 Assembly, Strainer 150 063369 - 1
3 Base - Pump (Strainer Housing) 003071 - 3
4 Bolt Hex Hd Finished 3/8-16 X 0.88 K47659 - 2
5 Bolt Hex Hd Finished 3/8-16 X 1.00 K01902 - 8
6 Bolt Hex Hd Finished 3/8-16 X 1.25 K01903 - 12
7 Bolt Hex Hd Finished 5/16-18 X 1.00 K07565 - 4
8 Bolt, Carriage 5/16 -18 X 3/4 013030 - 4
9 Bushing, Hex Reducer 017169 - 1
10 Pipe TBE, 1/2 X 1-1/2 Zinc Plated R11979-39 - 1
11 Conduit Pump Motor M05602B001 - 1
12 Cover, Base Pump (Strained Housing) 003502 - 2
13 Elbow-conduit 1/2 X 90 F/f Casting 005030 - 1
14 Elbow Flanged 003603 - 1
15 Elbow Flanged 003602 - 1
16 Elbow 90 Flare Male Pipe 3/4 Q10001-20 - 1
17 Elbow-conduit 1/2 X 90 Deg. 025045 - 1
18 Expansion Union (Conduit) N16289-20 - 1
19 Fitting 1/2 Ct Elb Inv Fl 026045 - 1
20 Gasket- Flange (2-3/4) 027363 - 1
21 Gasket - Flange (2) 027361 - 5
22 Gasket-suction Seal 054205 - 1
23 Gearbelt 012129 - 1
24 Gearbelt, Pulley 047611 - 1
25 Gearbelt Pulley 047612 - 1
26 Lc P9567 Air Elim/strnr Assembly (includes A8196) 063287 - 1
27 Nut Hex w/ext Lock Washer 5/16 - 18 Thd Q12068-06 - 8
28 Pipe 2 X 1-1/4 044951 - 1
29 Pipe Plug Square Head 1 K02283 - 1
30 Pump Blackmer x 2UA M04731B101 - 1
31 Screw 3/8 - 16 x 1 1/4 HHC ZP Grd - 5 052020 - 4
32 Screw - 1/4 - 20 x 1 063284 - 1
33 Pipe Union, Female K22468 - 1
34 Scr 3/8 -16x 1 1-4 Hhc Zp Grd-5 052020 - 4
35 Strainer Basket 40 Mesh L/c 063284 - 1
36 Washer 21/64 X 19/32 X 1/16 P 068605 - 4
37 Washer 3/8 Sae - N 0.81 X 0.41 X 0.06 K66314 - 22
38 Washer 5/16 Sae - N 0.69 X 0.34 X 0.06 K65235-33 - 8
39 Washer Spring Lock 3/8 In. K73278-25 - 2
PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 131
9850K Self-contained Pump Ultra-Hi Hydraulics Section
Pump and Motor
