Hydraulic Area Section Upper Hydraulics - Meter, Manifold, and Valve
Page 30 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Valve and Manifold Options
Part Description Current Part Previous Part Quantity
Valve and Manifold 120 V M04607B001 - 1
Valve and Manifold 220 V M04607B002 - 1
Valve and Manifold 120 V with ATC M04607B003 - 1
Manifold, no Valve* M04607B005 - 1
Manifold, no Valve w/ATC* M04607B006 - 1
* Super-Hi and High Flow w/Satellite Feed
(Item 11)
7 1 In STD Pipe X 6.75 R11495-38 - 1
8 O-Ring 1.609 X 0.139 Q10068-14 - 1
9 Assembly Meter Check Valve K94254-01 - 1
10 O-RING 1.234 X 0.139 Q10068-09 - 1
11 2-stage Sol Valve and Filter Manifold Refer to “Valve
and Manifold
Options (Item 11)”
- -
12 Bolt, Hx Hd Sems, 5/16 - 18 X 1” LG Q10865-36 - 4
13 Bracket Meter Stabilizer and Hose Retriever M06217B001 - 1
14 Strainer Insert High Capacity R19457 - 1
15 RTD Probe Assembly (Canada Retail Only) Q13130-01 - 1
16 Thermowell, Meter Cover (Canada Retail Only) Q13131-01 - 1
17 Pipe Plug C-Sunk 1/8 (Canada Commercial Only) K44283 - 2
18 Pipe Plug C-Sunk 1/8 K46444 - 2
Not Shown - For 9140 only
19 Angle Bracket M07342B001 - 1
20 Screw 5/16 X 7/8 Q11889-15 - 5
Item # Part Description Current Part Previous Part Quantity
