Gasboy Atlas Commercial Series - Manual (Page 140)

Item # Part Description Current Part Previous Part Quantity
1 Assembly, Conduit Valve Single 115 V M05687A001 - 1
Assembly, Conduit Valve Single 230 V M05687A002 - 1
2 Body - Check Valve 012003 -
3 SCR 1/4-20 X 2 HHC K01914-71 - 4
4 Discharge Grommet 028975 - 1
5 Elbow 1-1/2 X 1-1/4 X 90º Painted Red Z07941 - 1
6 Elbow 1 - 1-1/2 90º 150 PSI MI K46046 - 1
7 Elbow, Meter Discharge ATC 097907 - 1
8 Gasket-Seal Suction; 2-7/16 054190 - 1
9 Gasket Flange (1-1/2”) 027362 - 2
10 Nipple FE Pipe 1-1/2 X 1.75 R11493-77 - 1
11 Nippl FE Pipe 1-1/2 X 14.00 R11533-28 - 1
12 Nippl FE Pipe 1-1/2 X 3.75 R11493-26 - 1
13 Pipe Plug C-Sunk 1/8 K46444 - 2
14 Pipe Union, Female K12179 - 2
15 Reducing Bushing Hex 1-1/4 X 1 K02309-22 - 1
16 Washer 21/64 X 19/32 X 1/16 P 068605 - 4
Ultra-Hi Hydraulics Section 9850KX Single Inlet, Single Discharge Dispenser
Page 134 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Discharge Single Dispenser Valve w/Sat
Item # Part Description Current Part Previous Part Quantity
1 Assembly, Strainer 150 063369 - 1
2 Base - Pump (Strainer Housing) 003071 - 2
3 Bolt Hex Hd Finished 3/8-16 X 0.88 K47659 - 6
4 Bolt Hex Hd Finished 3/8-16 X 1.00 K01902 - 4
5 Bolt Hex Hd Finished 3/8-16 X 1.25 K01903 - 4
6 Cover, Base Pump (Strainer Housing) 003502 - 1
7 Flanged Elbow 026082 - 1
8 Gasket - Flange (2”) 027361 - 3
9 Gasket - Suction Seal 054205 - 1
10 Gasket Flange (1-1/2”) 027362 - 1
11 Manifold Strain/MTR 9850AXT 003017 - 1
12 Pipe 2” X 1-1/4” 044951 - 4
13 Pipe Plug Sq Head 3/8 K02280 - 1
14 Pipe Union, Female K22468 - 1
15 Screw - 1/4 20 X 1 051813 - 4
16 Washer 21/64 X 19/32 X 1/16 P 068605 - 4
17 Washer 3/8 Sae-N 0.81 X 0.41 X 0.06 K66314 - 6
18 Washer Spring Lock 3/8 In. K73278-25 - 2
Feedline Single
