Gasboy Atlas Commercial Series - Manual (Page 138)

Item # Part Description Current Part Previous Part Quantity
1 Assembly Check Valve Stem 062472 - 1
2 Assembly Conduit Valve Single 115 V M05687A001 - 1
Assembly Conduit Valve Single 230 V M05687A002 - 1
3 Body - Check Valve 012003 - 1
4 SCR 1/4-20 X 2 HHC K01914-71 - 4
5 Discharge Grommet 028975 - 1
6 Elbow 1 1/2 X 1 1/4 X 90 Painted Red Z07941 - 1
7 Elbow 1-1 1/2 90 150 Psi Mi K46046 - 4
8 Elbow, Meter Discharge 003608 - 1
9 Nut Hex Self Lock 10-32 Q10218-05 - 1
10 Gasket Seal Suction; 2-7/16 054190 - 1
11 Gasket Flange(1-1/2”) 027362 - 2
12 Nipple Fe Pipe 1 1/2 X 1.50 R11493-22 - 1
13 Nipple Fe Pipe 1 1/2 X 1.75 R11493-77 - 3
14 Nipple Fe Pipe 1/2 X 10.00 R11493-96 - 1
15 Nipple Fe Pipe 1 1/2 X 3.75 R11493-26 - 1
16 Pipe Union, Female K12179 - 2
17 Plate Plunger Check Valve 046050 - 1
18 Reducing Bushing Hex 1 1/4 X 1 K02309-22 - 1
19 Spring - Compression 057897 - 1
20 Washer 21/ 64 X 19/ 32 X 1/16 P 068605 - 4
Ultra-Hi Hydraulics Section 9850K Self-contained Pump
Page 132 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Discharge Pump Valve
Item # Part Description Current Part Previous Part Quantity
1 Assembly, Tube Supply M06615A001 - 1
2 Assembly, Float Chamber - 150 026474 - 1
3 Bracket Sump M05577B001 - 1
4 Elbow 90 Flare Male Pipe 3/4 Q10001-21 - 1
5 Fitting, 1/2 Ct Elb Inv Fl 026045 - 1
6 Fitting, 3/8 Ct Elb Inv Fl 026044 - 1
7 Fittings - Tube, Male Connector Inverted Flare 026047 - 1
8 Screw, Hex Ser Flng Hd 5/16 - 18 X 0.62 Q10253-02 - 1
9 Screw, Tf, Hex Washer Hd M8 X 18 M00417B009 - 2
10 Tube Assembly Return M05624A001 - 1
11 Tube Assembly Vent M05622A001 - 1
Sump and Tubing
