PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 167
Atlas Kits
M06391K001 Satellite Piping Conversion Kit 9153KX and 9853KX, 115 V
SGL
1 per unit MDE-4514
M06391K002 Satellite Piping Conversion Kit 9153KX and 9853KX, 115 V
Dual
M06391K003 Satellite Piping Conversion Kit 9153KX and 9853KX, 230 V
SGL
M06391K004 Satellite Piping Conversion Kit 9153KX and 9853KX, 230 V
Dual
M06422K001 Satellite Piping Kit Ultra-Hi 1Grade Dispenser
M06422K002 Satellite Piping Kit Ultra-Hi 2Grade Disp 1 per unit MDE-4514
M06422K003 Satellite Piping Kit Ultra-Hi 1Grade Pump
M06430K001 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Electronic 1GR 1HS
1 per unit
MDE-4522
M06430K002 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Electronic 2GR
M06430K003 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Electronic 1GR 2HS
M06430K004 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Mechanical 1GR 1HS
M06430K005 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Mechanical 2GR
M06430K006 Vapor Recovery Complete Kit
w/HHR
Atlas Self-contained
Mechanical 1GR 2HS
M06648K001 Discharge Piping Kit, 1” NPT Atlas STD Models 1 per hose MDE-4533
M06656K001 S/W, Standard 9800K M06656K00X are Atlas 9800
Serial EEPROM boards used
for reprogramming
M06333KXXXX CPU Boards
1 per unit M02775, M06656
M06656K002 S/W, Ultra-High 9850
M06656K003 S/W, Super-Hi 9840K
M06656K004 S/W, Standard 9800Q
M06656K005 S/W, Super-Hi 9840Q
M06656K100 S/W, Standard 9800K, Ultra-High
9850, Super-Hi 9840K, Standard
9800Q, Super-Hi 9840Q
Consists of M06656K001 -
K005 (Used for
reprogramming
M06333KXXXX CPU
Boards)
1 per unit M02775, M06656
M06699K001 Motor Kit, 1 HP 60 Hz 1PH Atlas Self-contained 1 per hose MDE-4541
M06699K002 Motor Kit, 1 HP 50 Hz 1PH Atlas Self-contained
M06731K001 Field Attachments Kit for Factory
Installed Vapor Recovery
Atlas Self-contained 1 per hose MDE-4487
M06874K001 Mechanical Hand Drive Atlas STD and
Self-contained Pumps
1 per grade MDE-4557
M06875K001 ATC Retail Kit Single w/Pulse-out Atlas Electronic Retail
Models 88K
1 per unit MDE-4556
M06875K002 ATC Retail Kit Dual w/Pulse-out
M06897K001 Heater Kit, Display Battery Backup,
115 V
Atlas Electronic Models Only
1 per unit
MDE-4555
M06897K002 Heater Kit, Display Battery Backup,
230 V
M06804K002 Air Gap Rain Baffle Kit Atlas Electronic Models Only 1 per unit MDE-4548
M06943K001 Mechanical Tot, Gal Atlas Ultra-Hi Models 1 per hose MDE-4568
M06943K002 Mechanical Tot, Lit
M08400K001 Kit, Atlas Bezel Installation Atlas Standard Models 1 per unit MDE-4740
Kit Number Description Used On Quantity MDE/Drawing
