Ultra-Hi Commercial Printed Circuit Boards Commercial Ultra-Hi PCBs
Page 152 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Pulse-out I/F/RS-485 I/F
PCA, Pulse-out I/F with Electromechanical
K-Pump, RS-485 with Totalizer
Item # Part Description Current Part Previous Part Quantity
1 PCA Atlas 9800, Pulse-out I/F (Dual Common/Distinct Outputs,
Two Dual Common Outputs) with Electromechanical Totalizer
M06587A001 C06425 (Dual Distinct Outputs)
C06746 (Dual Common Outputs)
1
2 PCA, K-Pump, RS-485 with Totalizer M05248A001 - 1
