PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 127
Mechanical Totalizer Ultra-Hi Meter and Pulser Section
Mechanical Totalizer
(2) Nut Hex W/Ext Lock Washer 6-32
(Q12068-02)
Odometer 039826 US Gallons
039836 Liters
(2) Screw PPHD 6-32 x .50
(Q11270-36)
(2) Nut Hex Flange M4
(M00414B005)
Shielded Flex Cable Assembly
(017365)
Totalizer
Bracket
(015129)
Spirol Pin (Q10038-29)
Description Current Part Previous Part Quantity
Not Shown
Totalizer Window 069077 - 1
Cotter Pin-Meter Gear K02137-29 - 1
