Item # Part Description Current Part Previous Part Quantity
1 Assembly, Conduit Valve Dual 115 V M05688A001 (See note 1) - 2
Assembly, Conduit Valve Dual 230 V M05688A002 (See note 1) - 2
Assembly, Conduit Valve Dual 115 V M05687A003 (See note 2) - 2
Assembly, Conduit Valve Dual 230 V M05687A004 (See note 2) - 2
2 Discharge Grommet 028975 - 2
3 Elbow 1-1/2 X 1-1/4 X 90’ Painted Red Z07941 - 2
4 Elbow 1 - 1-1/2 90’ 150 PSI MI K46046 - 4
5 Elbow, Meter Discharge 9850AXTW ATC 003151 - 2
Elbow, Meter Discharge 9850AXTW 003152 - 2
6 Gasket-Seal Suction: 2-7/16 054190 - 2
7 Gasket Flange(1-1/2”) 027362 - 4
8 Nippl FE Pipe 1-1/2 X 1.50 R11493-22 - 2
9 Nippl FE Pipe 1-1/2 X 6.56 R11493-46 - 2
10 Nippl FE Pipe 1-1/2 X 4.50 R11493-21 - 2
11 Nippl FE Pipe 1-1/2 x 6.12 R11493-93 - 2
12 Nippl FE Pipe 1-1/2 x 7.50 R11493-20 - 2
Nippl FE Pipe 1-1/2 x 10.00 R11493-96 (See note 2) - 2
13 Pipe Plug C-Sunk 1/8 ATC K46444 - 4
14 Pipe Union, Female K12179 - 2
15 Reducing Brush Hex 1-1/4 X 1 K02309-22 - 2
16 Screw 1/4 - 20 X 1 051813 - 8
17 Washer 21/64 X 19/32 X 1/16 P 068605 - 8
Notes: 1) This part is for 9850KXTW2.
2) This part is for 9850KXTW1 and 9850KSXTW1-M. Units built after August 2007.
Ultra-Hi Hydraulics Section 9850KXTW1 Single Inlet, 9850KXTW2 Dual Inlet, Dual Discharge Dispenser
Page 136 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Discharge Dual Dispenser Valve (115 V) w/Sat
Item # Part Description Current Part Previous Part Quantity
1 Manifold Strainer 9850AXT W1 003018 - 1
2 Pipe 1” Dia X 2” (not shown) 038065 - 1
3 Pipe Union, Female (not shown) K22468 - 1
4 Gasket - Suction Seal (not shown) 054205 - 1
5 Gasket Meter 027005 - 2
6 Flange Strainer Machined 9850AXTW1 026205 - 2
7 Bolt Hex HD Finished 3/8-16 X 1.00 K01902 - 16
Inlet Manifold, Model 9850KXTW1-M
