PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 55
Commercial Front (Dual Depicted) Commercial Electronics Section
Commercial Electronics Section
Commercial Front (Dual Depicted)
Pulser
CPU Pulser
Power Supply
Pulse-out/
RS-485 PCB M04768A001
PCB Support AC and DC
Conduit Wire
Electronics
Display PCB
Back Light Assembly Motor Relays
