Mechanical Pulser Option Single Unit Volume
Page 110 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
6 Pulser and Coupling Assembly
• Pulser and Coupling Assembly 10:1 Volume 1 046973 - 1
• Pulser and Coupling Assembly 100:1 Volume 4 046972 - 1
• Pulser and Coupling Assembly 1:1 Volume 5 046969 - 1
7 Elbow Conduit 1/2 X 45 M/F All except 3 025015 - 1
8 Screw, Hex Head Cap, Finished All - - 3
9 Pin, Spirol 5/64 X 7/16 STD PL All Q10038-35 - 1
10 Hub-Quan. Shaft Extension All 031035 - 1
11 Gear, Quantity All 027041 - 1
12 Ring Ret 5133-25-ZF All K76238-41 - 1
13 Plate and Idler Gear Assembly All 027044 - 1
14 Screw, Hex, Washer Head 1/4-2 All - - 1
15 Union Conduit M & F 1/2 All Q10016-04 - 1
16 Nipple Conduit 1, 3, 4, 5 R11976-57 R11976-74 1
17 Conduit Tee, Machined All 064830 - 1
18 Elbow Conduit 1/2 X 90 M/F 1, 3, 4, 5 025045 - 1
19 Nipple Conduit 1/2 X 1-5/8 1, 3, 4, 5 R11976-43 - 1
20 Elbow Conduit 1/2 X 90 F SPT 1, 3, 4, 5 K42428 - 1
21 Conduit 1, 4 M05292B001 - 1
22 Plug Pipe 1/2 SQ Socket 1, 3, 4, 5 K43850 - 1
Not Shown
23 Tie Wrap All C08682 - 1
24 Conduit 1/2 X 3 2, 6 038125 - 1
25 Conduit, EK 2, 6 M05221B001 - 1
26 Conduit Formed 3, 4, 5 M05368B001 - 1
27 Washer, Flat 0.875 X 1.62 X 0.56 2, 6 N16599-59 - 2
28 Conduit 1/2 - 3-3/4 NPS 2, 6 021737 - 1
29 Pipe TBE, 1/2 X 1-1/2 Zinc Plated 2, 6 R11979-39 - 1
30 Elbow Conduit 1/2 X 90 F/, F 2, 6 025030 - 3
Item # Part Description Where Used Current Part Previous Part Quantity
Where Used:
All = All Mechanical Single Units
1 = Pulser 10:1, gallons, Commercial and Retail, no EK 4 = Pulser 100:1, gallons, Commercial and Retail, no EK
2 = Pulser 10:1, gallons, Commercial only, with EK 5 = Pulser 1:1, liters, Commercial only, no EK
3 = Pulser 100:1, gallons, Retail only, (money) 6 = Pulser 1:1, liters, Commercial only, with EK
