Item # Part Description Current Part Previous Part Quantity
1 Discharge Line Assembly Super-Hi GR 1 M05560A001 - 1
2 Discharge Line Assembly Super-Hi GR 2 M05561A001 - 1
3 Hydraulic Manifold M05552B010 - 1
4 O-Ring 1.234 X 0.139 Q10068-09 - 4
5 Screw Metric M8 X 16 M00415B009 - 8
6 Bracket Manifold Support M06244B001 - 1
7 Screw, TF, Hex Washer HD M8 X 16 M00417B009 - 4
8 Nipple Std Pipe 1-1/4 X 7-9/16 Inch NPT R11494-68 - 1
9 Bushing, Hex Reducer K57268 - 1
10 Reducing Bushing Hex 1-1/4 X 1 K02309-22 - 1
11 Discharge Grommet 028975 - 2
12 Nipple FE Pipe 1-1/2 X 2.50 EH R11493-52 - 1
13 Elbow 1-1/2 X 1-1/4 X 90º Painted Red Z07941 - 1
14 Elbow, 1/2 X 90M X F K42448 - 1
15 Conduit, Valve M07354B001 - 1
16 Pipe Plug Sq. Head 1-1/4 K02284 - 1
17 1” NPT Plug K78953-27 - 1
18 Solenoid Valve 115 V 067028 - 1
Solenoid Valve 230 V 067062 - 1
Hydraulic Area Section 9140K, 9840K Super-Hi Discharge Piping
Page 40 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
