Ultra-Hi Commercial Printed Circuit Boards Combo Satellite Control Board
Page 154 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Combo Satellite Control Board
M07419A001 (115 V) and M07419A002 (230 V)
1
3
2
Item # Part Description Current Part Previous Part Quantity
1 Board, SAT Control 115 V M07366A001 - 1
Board, SAT Control 230 V M07366A002 - 1
2 Bracket, SAT Board M07276A001 - 1
3 Screw, metric Pan Head SEMS M4 X 12 Q12845-59 - 2
Not Shown
4 Circuit Board Support Q10651-46 - 4
