PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 123
Lower Welded Frame - Ultra-Hi (Self-contained) Ultra-Hi Frame Section
Lower Welded Frame - Ultra-Hi (Self-contained)
Note: Units built after 12/11/2008.
1
4
3
2
6
5
Item # Part Description Current Part Previous Part Quantity
1 Assy, Frame Weldment M08928A012 - 1
2 Mount, Universal M04871B001 - 4
3 Flat Washer M00959B008 - 4
4 Assy, Pump Support Plate M05536A001 - 1
5 Screw Metric M8 X 40 M00415B017 - 4
6 Washer, Flat M20 STL ZNPL M00959B019 - 4
