OM SYSTEM Tough TG-7 Digital Camera (Red) - Manual (Page 112)

A P icon will appear on the selected images. Press the OK
button again to remove the P icon.
Image Overlay
RAW RAW RAW
RAW
RAW RAW RAW
Back Set
Adjust the gain for each of the images in the overlay.
Highlight images using the HI buttons and adjust gain
using the FG buttons.
Gain can be adjusted in the range 0.1 – 2.0. Check the results
in the monitor.
Ч1.5 Ч1.5 Ч0.3 Ч0.5
Image Overlay
Back Set
Combining pictures (Image Overlay)
Overlay existing RAW photos to create a new picture. Up to 3 pictures can be included in the overlay.
The results can be modified by adjusting brightness (gain) separately for each picture.
Play the photograph back and press the OK button.
Select [Image Overlay] and press the OK button.
Select the number of images to be overlaid and press the OK button.
Highlight RAW images for the overlay using FGHI and press the OK button.
An overlay will be displayed once the number of images selected in Step 3 have been
selected.
Press the OK button. A confirmation dialog will be displayed.
Highlight [Yes] and press the OK button.
The image is saved with the image quality set at the time the image is saved (if [RAW] was selected
for image quality, it will be saved as [
L F+RAW]).
Overlays saved in RAW format can in turn be combined with other RAW images to create overlays
containing 4 or more pictures.
112
Combining pictures (Image Overlay)
1.
2.
3.
4.
5.
6.
B
B
