OM SYSTEM Tough TG-7 Digital Camera (Red) - Manual (Page 15)

Lens
Lens ring (removable) (
P.239 )
Self-timer lamp/LED illuminator/AF illuminator
(
P.60 , P.67 , P.145 )
Internal flash ( P.64 )
Connector cover ( P.23 )
Connector cover lock ( P.23 )
Lock knob ( P.23 )
Speaker
Lens ring release button (
P.239 )
1
2
3
4
5
6
7
8
9
USB connector (Type-C) ( P.23 , P.182 )
HDMI connector (Type-D) ( P.159 )
Battery/card compartment cover ( P.19 )
Lock knob ( P.19 )
Battery/card compartment cover lock ( P.19 )
Tripod socket
Monitor (
P.31 , P.89 , P.154 )
Strap eyelet ( P.18 )
10
11
12
13
14
15
16
17
Names of parts
1
2
8
10
11
7
6
5
4
3
9
12
13
14
15
16
17
15
Names of parts
