Insert the card.
Slide the card in until it is locked into place.
1
Terminal area
1
Close the battery/card compartment cover.
While holding the battery/card compartment cover in the
direction indicated by
1 , slide the open/close knob of the
battery/card compartment cover and the lock knob to lock
the cover (
2 , 3 ).
When using the camera, be sure to close and lock the
battery/card compartment cover.
1
2
3
Turn off the camera before opening or closing the battery/card
compartment cover. To remove the battery, first push the battery
lock knob in the direction of the arrow, then remove it.
Do not remove the battery while the card write indicator is
displayed.
125 F5.6
ISO-A
200
L N
S-IS ON S-IS ON
0.0 0.0 01:02:03 01:02:03
1023 1023
P
FHD
30p 30p
F
1
Card write indicator
1
Do not forcibly insert a damaged or deformed card. Doing so may damage the card slot.
Removing the battery
Contact an authorized distributor or service center if you are unable to remove the battery. Do not
forcibly remove the battery.
20
Inserting and Removing the Battery and Card
3.
C
4.
C
C
