190M Series Medical ScopeMeter
Users Manual
128
Electromagnetic Immunity
The Fluke Biomedical190M Series test tools, including standard accessories, conform with the EEC directive 2004/108/EC
for EMC immunity, as defined by EN-61326-1, with the addition of the following tables.
Trace disturbance with VPS410 voltage probe shorted (Scope Mode, 10 ms/div):
Table 3. (E = 3V/m)
Frequency
No Disturbance
Disturbance < 10% of full
scale
Disturbance > 10% of full
scale
80 MHz – 700 MHz
All other ranges
100, 200, 500 mV/div
2, 5, 10, 20, 50 mV/div
700 MHz – 1 GHz
All other ranges
10 mV/div
2, 5 mV/div
1.4 GHz – 2.7 GHz
All ranges
Meter Mode (Vdc, Vac, Vac+dc, Ohm and Continuity): Reading disturbance with test leads shorted
Table
4
No visible disturbance
E = 3V/m
Frequency range 10 kHz to 1 GHz
500 mV to 1000 V , 500 Ohm to 30 MOhm ranges
Table 5
No visible disturbance
E = 3V/m
Frequency range 1.4 GHz to 2 GHz
500 mV to 1000 V, 500 Ohm to 30 MOhm ranges
