SYNC (MMR-Bus) Connector pinout
PIN #
Signal Description
PIN #
Signal Description
1
CAN_BUS+
9
CAN_BUS-
2
CCLK_BUS0+
10
CCLK_BUS0-
3
CCLK_BUS1+
11
CCLK_BUS1-
4
CCLK_BUS2+
12
CCLK_BUS2-
5
CCLK_BUS3+
13
CCLK_BUS3-
6
+12 TERM PWR
14
Frame ground
7
CAN LEFT TERM
15
CAN RIGHT TERM
8
N/C
NOTES:
1. 15-pin D-subminiature female connector (DB-15). The two connectors are
paralleled in the MMP-16 and either can be used as an input or output.
2. TASCAM supplies a 3 foot interface cable, 70447. The differential signals
should be routed on twisted pairs of wires.
TIMECODE IN Connector
PIN #
Signal Description
TIP
Time Code Reader +
Ring
Time Code Reader -
Sleeve Ground
NOTES:
1. 1/4” TRS Phonejack
2. 10K Ohm input impedance. Differential input.
TIMECODE OUT Connector
PIN #
Signal Description
TIP
Time Code Reader +
Ring
Time Code Reader -
Sleeve Ground
NOTES:
1. 1/4” TRS Phonejack
2. Differential op-amp output circuit.
