TASCAM MMP-16 Owner’s Manual • Chapter 3 • Keys and Status Displays MMP-16 52
Slip Track State Display
In the Slip Track state, the display will show the current time position in the top line of the display (the
same as in the Normal state), while the bottom line of the display is used to show the contents of the slip
register for the selected track. If more than one track is selected, all of their registers are active, but only
the last selected track indexes slip register will be shown.
01234567890123456789 LCD character positions (left to right)
Label HH:MM:SS:FF.xx Top: (Operator message) same as Normal state
SlipX HH:MM:SS:FF.xx Bottom: (X is the number of the currently selected track index,
Time code display is the slip register for the selected track index)
To increment or decrement the slip register amount for the selected track index, use the Up/Down arrow
keys or the Wheel. To clear a slip register, set the slip amount to zero (0), or hold the clear key while also
pressing the appropriate track SEL key. To directly enter a slip time into a slip register, use the keypad
while in the Normal state to enter the desired slip time amount, then press STO followed by pressing the
appropriate track SEL key.
Load Track State Display
In the Load Track state, the display is used to show the directory of all Edit Decision Lists or EDLs
(Projects, Sessions, and Compositions) on all mounted drives. Use the wheel or the Up/Down arrow keys
to scroll through the list of projects. Press STO to automatically load the first sixteen tracks of the Project
into the sixteen MMP track indexes.
01234567890123456789 LCD character positions (left to right)
Project: Top: (Operator message)
nnnnnnnnnnnnnnnnnn Bottom: (nnn is the project name, use wheel or Up/Down arrows to scroll
Pressing the Load Track key again shows the next level of the EDL hierarchy for the chosen project
(usually the Track name) and allows for scrolling through the list of tracks in the Project, and loading any
track into the selected track index.
01234567890123456789 LCD character positions (left to right)
Load into Track X: Top: (X is the currently SELected track index)
o
nnnnnnnnnnnnnnnnnn Bottom (
o
indicates an unloaded track, and nnn is the track name)
If a track from the list of available tracks has already been loaded into an MMP track index, the display
will ask if you wish to move that track into the currently selected Track index. If accepted, this action will
remove the track from its previous Track index location, thus leaving it blank.
01234567890123456789 LCD character positions (left to right)
Move Track X
à à Y
Top: (X is the Track index into which the listed track is
already loaded, Y is the currently SELected track index)
X nnnnnnnnnnnnnnnnnn Bottom: (X is the Track index into which the listed track
is loaded, and nnn is the track name)
To move a loaded track from its current Track index position into the selected Track index or to load a
currently unloaded track into the selected Track index, scroll through the list of available tracks until the
desired track is located. The display will indicate your choice of both the selected track to be moved or
loaded, and the destination Track index. Press the STO key to complete the operation and load the track.
