Machining Operations
 Positions or point pattern: Define the positions at which the TNC
is to machine the contour pocket (see “Defining Machining Positions”
on page 145.)
„ Specify via soft key for each subcontour whether it is a
pocket or an island.
„ As a rule, always start the list of subcontours with a pocket
(if required, the deepest pocket)!
„ On the contour detail form you can define up to a
maximum of nine subcontours.
