Processing DXF File
s (Software
Option)
Opening a DXF file
The DXF converter can be started in different ways:
„ From the file management if you want to extract several contour or
position files consecutively
„ From the form during the machining definition of units 125 (contour
train), 122 (contour pocket) and 130 (contour pocket on point pattern) if
you are supposed to enter the names of the contours to be machined
„ While defining the machining, if you enter the machining positions via
point files
Starting the DXF converter through the file management
 Select the smarT.NC operating mode
 Call the file manager.
 In order to see the soft-key menu for selecting the file type
to be displayed, press the SELECT TYPE soft key.
 In order to show all DXF files, press the SHOW DXF soft
key.
 Select the desired DXF file, and load it with the ENT key.
smarT.NC starts the DXF converter and shows the contents
of the DXF file on the screen. The TNC shows the layers in
the left window, and the drawing in the right window.
The TNC automatically saves the datum defined by you and
the current zoom condition upon exiting the DXF converter.
If you want to open the same DXF file again, the TNC loads
this information (valid for the previously selected file).
