189
Processing DXF File
s (Software
Option)
If necessary you can also deselect elements that you
already selected, by clicking the element in the right window
again, but this time while pressing the CTRL key.
To save the selected contour elements in a plain-language
program, enter any file name in the pop-up window
displayed by the TNC. Default setting: Name of the DXF file
Confirm the entry: The TNC saves the contour program in
the directory in which the DXF file is also saved.
If you want to select more contours, press the CANCEL
SELECTED ELEMENTS soft key and select the next contour
as described above.
If you have selected polylines, the TNC shows a two-level ID
number in the left window. The first number is the serial
contour element number, the second element is the element
number of the respective polyline from the DXF file.
