2-2 W A N s u i t e 5 1 6 5
completeness and the unit has been checked both mechanically and
electrically.
Supplied Materials
The WANsuite 5165 ships with the following standard items:
• WANsuite 5165 unit (card and rear module or card without rear module)
• T1 network cable
•
Serial (Supervisory) cable
•
Verilink documentation CD
For specific applications, see Optional Equipment on page A-6 for additional
cables and adapters. Contact Verilink Technical Support (see page xii) for
further assistance.
Configuring the Unit’s IP Address
The WANsuite 5165 can be configured and monitored through the Web
Server interface or the VT100 interface, but the unit must first be configured
with an IP address. You can configure the unit’s IP address using the Verilink
Configuration Wizard, which is included on your documentation CD.
NOTICE: You may also access the Verilink Configuration Wizard on the
Verilink Web site: www.verilink.com.
Installation Wizard
To configure the IP address using the Verilink Configuration Wizard, follow
the steps listed below:
1 Using the supplied cable, connect the unit’s RJ-11 Supervisory port to a
COM port on your PC. (Take note of which COM port is connected.)
2 Insert the Verilink CD (provided with the WANsuite 5165) into your PC’s
CD-ROM drive.
3 Use Windows “Explore” to view the contents of the CD and select the
folder labeled “Utilities.” In this folder will be a file named
ipwiz.exe ;
this executable file is the Verilink Configuration Wizard application.
