Kayak HD — Installation and Service Manual 111
Panel Lock
This means that (almost) all menus are accessible, but no value on main-
frame or panel can be changed. The text
Locked is displayed in all menus.
The panel cannot be detached. When the panel is locked, the attached side
panel is also locked.
To lock the Kayak HD control panel in DD Mode ( Figure 68 ):
1. Press and hold the button TransDur along with the button Store in the
Effects button section of the panel.
2. Using the numeric buttons, enter the password 3511 and press Enter .
Figure 68. Locking the Panel from the Effects Button Section in DD Mode
To lock the Kayak HD control panel in Default Mode ( Figure 69 ):
1. Press and hold the button TransDur along with the button Lock Learn in the
Effects button section of the panel.
2. Using the numeric buttons, enter the password 3511 and press Enter .
