178 Kayak HD — Installation and Service Manual
Section 4 — Maintenance
9. Remove the Display Board from the housing.
10. Insert the new Display Board using the preceding instructions and see
Table 13 below for reference.
Table 13. Kayak Display Board—Connections Reference
From To Notes
RY4540/J3/20 Pin RY4510/J7/20 Pin
RY4540/TFT Display RY4510/J6/40 Pin
RY4540/J1/50 Pin RY4510/J14/50 Pin
RY4520/J1/50 Pin RY4510/J15/50 Pin
RY4530/J1/50 Pin RY4510/J17/50 Pin Crosspoint Switchboard 2
RY4550/J1/50 Pin RY4510/J21/50 Pin
RY4530/J1/50 Pin RY4510/J22/50 Pin Crosspoint Switchboard 1
