52 Kayak HD — Installation and Service Manual
Section 2 — Installation
2 M/E Control Panel
Figure 27. Kayak HD 150C and 200C Control Panel Dimensions 1 of 2
418 mm
16.46 in.
398 mm
15.66 in.
10 mm
0.39 in.
34 mm
1.31 in.
16 mm
0.60 in.
11 mm
0.40 in.
65 mm
2.55 in.
81 mm
3.19 in.
260 mm
10.23 in.
1445 mm
5.69 i
n.
8451_08_
r2
20°
7°
