200 Kayak HD — Installation and Service Manual
Appendix A — Specifications
Table 20. Serial Digital Video Inputs
Table 18. Control Panel Connection
Type of connection 10/100 Base T
Protocol TCP(UDP)/IP
Cable and connectors CAT5 UTP, RJ45 connectors;
Max. Cable Length 100m / 300ft
1 Frame and up to 4 Panels connect without use of external hub/switch.
Table 19. Power
4 RU Frame
Line voltage
100V-240V AC +/-10% autorange, power factor corrected. Automatic line-
voltage sensing for 120V and 240V sources.
Line frequency 50/60Hz +/- 5%
Power consumption max. 400W
Leakage current < 2.5 mA
DC-OUT for control panel 48V DC, max 3A
8 RU Frame
Line voltage
100V-240V AC +/-10% autorange, power factor corrected. Automatic line-
voltage sensing for 120V and 240V sources.
Line frequency 50/60Hz +/- 5%
Power consumption max. 800W
Leakage current < 2.5 mA
DC-OUT for control panel 48V DC, max 3A
Kayak HD 100C Control Panel
DC-IN 48V DC In, max 1.3A
Kayak HD 150C, 200C, 200 Control Panel
DC-IN 48V DC In, max 1.3A
Kayak HD 250C AND 250 Control Panels
DC-IN 48V DC In, max 1.3A
Kayak HD 300 Control Panel
DC-IN 48V DC In, max 1.3A
KDD-PSU Frame (Remote Control Panel Power Supply)
Line voltage 100V-240V AC +/-10%, power factor corrected
Line frequency 50/60Hz +/- 5%
Power consumption max. 375W
Leakage current < 2 mA at 250V AC
Format
ITU-R656, SMPTE 259M, 270Mbit/s.
SMPTE 292M, 1.5Gbit/s
