Kayak HD — Installation and Service Manual 207
Supported GVG200 Commands
Supported GVG200 Commands
Note The GVG DSK command is always translated to the Kayak HD PP mixer effect.
Note Standard GVG200 protocol timing is used. Commands are executed in the
third field after response.
Name Command Code Remark
TRANSITION MODE COMMAND CA Only Write
TRANSITION RATE COMMAND CC/CD Only Write
TRANSITION PUSHBUTTON SELECT COM-
MAND
FB
CROSSPOINT BUS COMMAND
C1-C4
(C1-CF for AUX)
41-44
(41-4F for AUX)
Crosspoint interpretation:
GVG code Interpretation
01H...0x14INPUT 1...20
15HME1 OUT
16HME2 OUT
17HCLEAN FEED
18HMAIN OUT
21HME3 OUT
25H...27HCOLOR BGD 1...3
30H...4BHINPUT 21...48
AUX buses:
The number of AUX buses is not limited. If the effect address is 07H (= AUX Cros-
spoint) the lower nibble of the command code will be interpreted as the AUX bus
number. Up to 15 AUX buses can be controlled.
PUSHBUTTON COMMAND
C6
(C7 for REV,KEY CUT
keyer 1, KEY CUT
keyer 2)
Only MIX,WIPE, REV and KEY CUT are supported.
MIX and WIPE will switch the currently selected buttons for next transition to the
given state.
WIPE PATTERN SELECT COMMAND C8 Only Write
ALL STOP COMMAND F2
LEARN E-MEM REGISTER DA
RECALL E-MEM REGISTER DB
